RoadVac CS-10
Automatic, and the one coach builders specify. The CS-9 with a circuit board added. That board is what makes the system automatic — open a VacPort or an inlet valve and the vacuum starts by itself. It is the configuration most often specified from the factory.
- Opens a VacPort and starts on its own
- The usual factory-installed configuration in premium towables
- Takes the Y11 double-opening bag
Best for: OEM installs and premium towables. Takes the Y11-5 dust bag.
CS-10 shown; it shares the CS-RM housing.
Buy
Replacement unit, or the complete system.
Every RoadVac is sold both ways — the bare power unit for a swap, or the full system with everything the install needs.
Built to order
The CS-10 is a current, supported model that we build to order rather than stock online. Tell us the coach and whether you need the complete system or a replacement unit only, and we will come back with a price and a lead time.
Request a price by email Call 772.463.1400Mon-Fri 8:00am-3:30pm ET
Need bags or parts for a CS-10 you already own?
Those are in stock and ship the same way as everything else.
Y11 bags and filters CS service partsCS-10 specifics
What makes this one different
| Installation | Dual inlet |
|---|---|
| Operation | Automatic |
| Inlet valve | Included |
| Front utility inlet | Yes |
| VacPort compatible | Yes — automatic |
| Circuit board | Yes |
| Dust bag | Y11, double opening |
Cleaning points
Two ways to pick up dirt.
The CS-10 is a piped system, so it takes both. An inlet valve is where the hose plugs in. A VacPort takes the place of a dust pan — open its door and the vacuum starts, then sweep the dirt straight into it and it travels down the pipe to the dust bag. No hose, no bending down.
The complete install kit, the A-950-X, is $65.96 and includes the LED VacPort, trim plate, elbow, coupling, sweep tee, 3 ft of hose, wire and nuts.
Full specifications
Shared across the whole RoadVac line
| Air watts | 414 |
|---|---|
| Water lift | 92 in. sealed / 52 in. working |
| Airflow | 107 CFM max / 38 CFM working load |
| Motor | 1,200 watts |
| Current draw | 12A at 60Hz / 5.9A at 50Hz |
| Power source | 110V or 220V (240V single phase on request) |
| Sound level | 74.6 dB |
| Bag capacity | 0.5 gallon |
| Filtration | HEPA type, sealed dust bag |
| Coverage | Up to 900 sq. ft. |
| Hose | 35+ ft stretch hose |
| Certifications | UL, CE and UKCA |
| Unit weight | 8 lbs |
| Shipping carton | 12 x 12 x 8 in. |
| Warranty | 2 years on the unit, 30 days on accessories |
Consumables
The Y11 bag is the one that seals.
The CS-10 takes the Y11-5 — five sealed HEPA-type bags and one motor filter. It has two openings, and the other RoadVac bag does not fit even though it looks almost the same on a shelf.
Change the motor filter after every fifth bag, which is why one ships in every pack. Non-genuine bags and filters void the vacuum warranty.
No tools with your coach? That is normal. Plenty of RV builders fit the vacuum at the factory but leave the hose and tool kit out, because the kit is sold separately. Nothing is wrong with your system — you just need the kit. Any 32 mm kit fits.
CS-10 questions
Common questions
Which dust bag fits the CS-10?
The Y11-5. It is the double-opening Y11 bag, sold in a pack of five with a motor filter. The other RoadVac bag will not seal in this unit, so check the opening count before you order.
Can I put a VacPort on a CS-10?
Yes. The CS-10 is a piped system, so it takes the whole VacPort range in LED and non-LED, plus inlet valves. Remember they do different jobs: the hose plugs into an inlet valve, while a VacPort is a sweep-in door that replaces a dust pan.
What tool kit fits the CS-10?
Any 32 mm kit, which is all of ours. There is no per-model tool kit — the TK108-B, TK108-TB and TK108-TBM all fit, and so do the individual wands, hoses and floor tools. The remote-control kit, the TK-108-TB-RC, is the exception: it needs a matching receiver and fits only the CS-RM-RC.
How much area will a CS-10 cover?
Up to 900 sq. ft., which covers any coach, and also a tiny home, a kitchen or a bath. Every RoadVac shares the figure — 414 air watts, 92 in. of sealed water lift and 107 CFM at maximum airflow.
The other five models
- RoadVac CS-6 — for rigs on a tight power budget
- RoadVac CS-8 — the simplest install in the range
- RoadVac CS-9 — two inlets, no electronics
- RoadVac CS-RM — hide the power unit, keep the reach
- RoadVac CS-RM-RC — on and off from the handle
- InterVac RM — not a RoadVac, but coach builders fit it too. Takes the Y08 bag.
